In digital office and entertainment scenarios, a docking station serves as an important hub for connecting multiple devices, and the proper functioning of its HDMI port directly affects the user experience with external monitors. When users report issues related to the HDMI Port of the docking station, a scientifically rigorous after-sales troubleshooting process becomes particularly important. The following will provide a detailed explanation on how to determine whether the HDMI port of the docking station is working properly based on the after-sales process.

1. Identify the Problem Points Accurately

——————————

When users provide feedback on display issues with the external monitor, the first step for after-sales personnel is to accurately identify the type of problem. The common problems mainly include the following categories:

a. Display Specifications Not up to Standard: The monitor cannot achieve the expected resolution, refresh rate, etc., for example, it should display 4K/60Hz images, but can only achieve lower specifications actually.

b. Display Abnormality: including phenomena such as Screen Flickering, Black Screen, and Blurry Screen. Screen flickering is characterized by frequent flickering of the screen image; Black screen means there is no display content on the screen; Blurry screen refers to abnormal images such as cluttered color blocks and stripes appearing on the screen.

c. Multi Monitor Connection Issue: When connecting dual or triple monitors, only one monitor has a display and the other monitors have no response.

d. Not Displaying at All: After connecting the monitor, the monitor remains in a black screen state without any signal input prompts.

Accurately identifying the type of problem can provide direction for subsequent troubleshooting work.

2. Comprehensive Understanding of Computer Configuration and Product Information

——————————

After identifying the problem, after-sales personnel need to further understand the specific configuration of the customer's computer, including interface specifications (such as DP1.2, DP1.4, etc.) and the SN Number of the product. The interface specifications of a computer play a crucial role in the connection and display effect between the docking station and the monitor. Different interface specifications support different display specifications and functions. The product SN number helps after-sales personnel to query the specific model, production batch, and other information of the docking station in order to more accurately determine whether there are known product or compatibility issues.

3. Targeted Settings Based on Computer Specifications

——————————

According to the different specifications of the customer's computer, after-sales personnel need to make corresponding settings and troubleshooting:

a. DP1.2 Specification Computer:

If a single monitor is connected and the display specification is not up to standard, the display specification of ordinary 2lane products is up to 4K/30Hz; if the display specification is not up to standard when dual-connected, for ordinary 2lane products, the display specifications of the two external monitors need to be manually reduced to 1080P to achieve normal display. This is because the DP1.2 interface has certain limitations in bandwidth and other aspects. When connecting multiple monitors or pursuing high-specification display, the display parameters may need to be adjusted.

b. Mac Computer (MacOS System):

For products with Mac system in SST Display Mode in the specification, when two or three external monitors display abnormally, due to the monitor operating frequency problem, you need to manually reduce the display refresh rate to 30Hz to restore normal display.

This is a compatibility issue that may occur when the Mac system is connected to multiple monitors, which can be solved by adjusting the refresh rate.

c. DP1.4 Specification (No DSC) Computer:

According to the existing information, most configurations before the 11th generation of the Intel platform do not have DSC (including Thunderbolt 3 Interface). When 8k products are used in such computers, the display specifications are generally 4K/60Hz for a single connection, and 4K/30Hz and 1080P60Hz for dual connections. If the display specifications do not meet the standards, you need to update the graphics card driver first. The update of the graphics card driver can optimize the signal transmission and display support between the computer and the docking station and the monitor.

d. DP1.4 Specification (with DSC) Computer:

Most configurations of Intel 11th generation platform and later have DSC, but a very small number of computers may not be able to enable DSC normally, and the display specifications are similar to those of computers without DSC. If the display specifications do not meet the standards, you also need to update the graphics card driver first.

e. Computer C Port Does Not Support Video:

If the computer C port does not support the video output function, then the external monitor cannot be displayed normally by connecting the HDMI port of the expansion dock through this port. You need to confirm the video output support of the computer port.

4. Upgrade the Program to Address Potential Issues

——————————

After completing the troubleshooting of the computer configuration specifications mentioned above, if the display problem still exists and it can be confirmed that both the computer configuration and specification settings are correct, it is likely that the HDMI port of the docking station is working abnormally due to software issues. At this point, after-sales personnel need to upgrade relevant programs, Like Firmware Programs for Docking Stations, computer operating system patches, graphics card drivers, etc. These program updates often fix known software vulnerabilities and compatibility issues, thereby resolving display issues with the docking station HDMI port.

Through the rigorous after-sales process mentioned above, from identifying problem points and understanding computer configurations to troubleshooting and upgrading programs based on specifications, after-sales personnel can accurately determine whether the HDMI port of the docking station is working properly and effectively solve related display problems, providing users with a stable and reliable multi device connection solution.
